HarmonyOS NEXT 实现滑动拼图验证码功能 原创

// CaptchaComponent.ets - 自定义验证码组件
@Component
struct CaptchaComponent {
  private controller: CaptchaController = new CaptchaController()
  @State blockPosition: number = 0
  @State isVerified: boolean = false
  @Link onVerify: (result: VerifyResult) => void

  build() {
    Column() {
      // 拼图区域
      Stack() {
        Image($r('app.media.verify_bg')) // 背景图
          .aspectRatio(1.78) // 16:9比例

        // 拼图缺口
        Canvas({ context: this.controller.canvasContext })
          .onReady(() => this.drawBlockShape())
          .width(this.controller.blockSize)
          .height(this.controller.blockSize)
          .position({ x: this.blockPosition })
      }
      .height(300)
      .clip(new Rect({ width: '100%', height: '100%' }))

      // 滑块控件
      Slider({
        min: 0,
        max: 100,
        value: this.blockPosition,
        style: SliderStyle.OutSet
      })
      .blockShade($r('app.graphic.thumb'))
      .onChange(value => {
        this.handleSliderMove(value)
      })
    }
  }

  private drawBlockShape() {
    const ctx = this.controller.canvasContext
    ctx.beginPath()
    // 绘制拼图形状（示例使用圆角矩形）
    ctx.arc(40, 40, 35, 0, Math.PI * 2)
    ctx.fillStyle = 'rgba(0,0,0,0.5)'
    ctx.fill()
  }

  private handleSliderMove(value: number) {
    if (this.isVerified) return;

    this.blockPosition = value
    // 验证逻辑
    if (Math.abs(value - this.controller.correctPosition) < 5) {
      this.isVerified = true
      this.onVerify({ success: true, time: new Date().getTime() })
    } else if (value >= 95) {
      this.onVerify({ success: false, retry: true })
    }
  }
}

// 使用示例
@Entry
@Component
struct VerifyPage {
  @State verifyResult: string = ''
  private maxRetries: number = 3
  @State retryCount: number = 0

  build() {
    Column() {
      Text(this.verifyResult)
        .fontSize(20)
        .margin(20)

      CaptchaComponent({
        onVerify: (result) => this.handleVerify(result)
      })

      Button('重新验证')
        .onClick(() => this.resetVerification())
    }
  }

  private handleVerify(result: VerifyResult) {
    if (result.success) {
      this.verifyResult = `验证成功 ${result.time}ms`
    } else {
      this.retryCount++
      if (this.retryCount >= this.maxRetries) {
        this.verifyResult = '超过重试次数'
      } else {
        this.verifyResult = `验证失败，剩余次数 ${this.maxRetries - this.retryCount}`
      }
    }
  }

  private resetVerification() {
    this.retryCount = 0
    this.verifyResult = ''
  }
}

// 控制器类
class CaptchaController {
  canvasContext: CanvasRenderingContext2D = new CanvasRenderingContext2D()
  blockSize: number = 80
  correctPosition: number = Math.random() * 250 + 50
}

// 类型定义
interface VerifyResult {
  success: boolean
  time?: number
  retry?: boolean
}
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
48.
49.
50.
51.
52.
53.
54.
55.
56.
57.
58.
59.
60.
61.
62.
63.
64.
65.
66.
67.
68.
69.
70.
71.
72.
73.
74.
75.
76.
77.
78.
79.
80.
81.
82.
83.
84.
85.
86.
87.
88.
89.
90.
91.
92.
93.
94.
95.
96.
97.
98.
99.
100.
101.
102.
103.
104.
105.
106.
107.
108.
109.
110.
111.
112.
113.
114.
115.
116.
117.

// resources/base/profile/main_page.json
{
  "media": [
    {
      "name": "verify_bg",
      "src": "$media:captcha_bg"
    }
  ],
  "graphic": [
    {
      "name": "thumb",
      "shape": {
        "type": "circle",
        "radius": 16,
        "fillColor": "#FF4081"
      }
    }
  ]
}
