前言：

鸿蒙-ArkTS和Native之间的交互使用5使用原生Zip模块开发解压缩功能-鸿蒙开发者社区

对于移动开发来说，原生的解压缩SDK往往满足不了用户的需求，比如鸿蒙的@ohos.zlib (Zip模块)就只支持zip格式的压缩包，也不支持获取压缩包内部列表和不解压获取压缩包的单个文件。

首先：

开发鸿蒙的解压缩功能，我们有三种方式：

1.使用原生@ohos.zlib (Zip模块)

2.使用OpenHarmony三方库jsZIP

3.使用native的三方库libarchive库开发。

还是先讲讲比较简单的开放方式——原生@ohos.zlib (Zip模块)

在应用沙箱目录下创建一个测试文件data.txt，并写入测试数据。示例代码如下。（app操作文件只能在沙箱里面操作）

import { fileIo as fs} from '@kit.CoreFileKit';
import { BusinessError, zlib } from '@kit.BasicServicesKit';


@Entry
@Component
struct Index {
  @State dataSize: number = 0;


  build() {
    Row() {
      Column() {
        // 在应用沙箱目录下创建文件data.txt，并写入测试数据
        Button('创建测试文件data.txt').onClick(() => {
          let path = getContext(this).filesDir;
          // 创建文件data.txt
          let inFile = fs.openSync(path + '/data.txt', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
          // 写入测试数据
          for (let index = 0; index < 100; index++) {
            fs.writeSync(inFile.fd, index + ': hello world, hello world, hello world, hello world, hello world.\n');
          }
          // 获取测试数据原始大小，并保存到dataSize中
          let stat = fs.statSync(inFile.path);
          this.dataSize = stat.size;
          console.info('dataSize: ' + this.dataSize);
          // 关闭文件
          fs.closeSync(inFile);
        })
      }
    }
    .height('100%')
    .width('100%')
  }
}

解压缩：

import { fileIo as fs} from '@kit.CoreFileKit';
import { BusinessError, zlib } from '@kit.BasicServicesKit';


@Entry
@Component
struct Index {
  build() {
    Row() {
      // 示例一：将测试文件data.txt压缩并归档到data.zip中。
      Button('compressFile').onClick(() => {
        let path = getContext(this).filesDir;
        let inFile = path + '/data.txt';
        let outFile = path + '/data.zip';
        let options: zlib.Options = {};
        zlib.compressFile(inFile, outFile, options).then((data: void) => {
          console.info('compressFile success, data: ' + JSON.stringify(data));
        }).catch((errData: BusinessError) => {
          console.error(compressFile errCode: ${errData.code}, message: ${errData.message});
        })
      })


      // 示例二：将data.zip文件解压到应用沙箱目录下。
      Button('decompressFile').onClick(() => {
        let path = getContext(this).filesDir;
        let inFile = path + '/data.zip';
        let outFile = path;
        let options: zlib.Options = {};
        zlib.decompressFile(inFile, outFile, options).then((data: void) => {
          console.info('decompressFile success, data: ' + JSON.stringify(data));
        }).catch((errData: BusinessError) => {
          console.error(decompressFile errCode: ${errData.code}, message: ${errData.message});
        })
      })
    }
    .height('100%')
    .width('100%')
  }
}

已知大小缓冲区的压缩与解压：

import { fileIo as fs} from '@kit.CoreFileKit';
import { BusinessError, zlib } from '@kit.BasicServicesKit';


@Entry
@Component
struct Index {
  @State dataSize: number = 0;  //用于保存原始数据的大小


  build() {
    Row() {
      // 示例一：读取data.txt文件内容并存入一个缓冲区，调用compress接口压缩缓冲区中的数据到目标缓冲区，并将目标缓冲区的内容写入文件data.bin
      Button('compress buffer').onClick(() => {
        let path = getContext(this).filesDir;
        let inFile = fs.openSync(path + '/data.txt', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        let outFile = fs.openSync(path + '/data.bin', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        // 读取data.txt文件的内容，并存入缓冲区inBuf
        let stat = fs.statSync(inFile.path);
        let inBuf = new ArrayBuffer(stat.size);
        let readLen = fs.readSync(inFile.fd, inBuf);
        console.info(original size: ${stat.size}, read len: ${readLen});
        // 获取原始数据的大小，并保存
        this.dataSize = stat.size;
        // 创建一个压缩对象实例
        let zip = zlib.createZipSync();
        // 获取一个目标缓冲区的上限
        zip.compressBound(stat.size).then((data) => {
          console.info(the max dest buf len is ${data});
          // 目标缓冲区outBuf
          let outBuf = new ArrayBuffer(data);
          // 将inBuf中的数据压缩到outBuf中
          zip.compress(outBuf, inBuf, readLen).then((zipOutInfo) => {
            console.info(compress success, status ${zipOutInfo.status}, destLen  ${zipOutInfo.destLen});
            // 将outBuf中的数据写入到data.bin文件
            let writeLen = fs.writeSync(outFile.fd, outBuf, { length: zipOutInfo.destLen });
            console.info(write destBuf to data.bin, writeLen ${writeLen});
            // 关闭文件
            fs.closeSync(inFile.fd);
            fs.closeSync(outFile.fd);
          }).catch((errData: BusinessError) => {
            console.error(errData is errCode:${errData.code}  message:${errData.message});
          })
        }).catch((errData: BusinessError) => {
          console.error(errData is errCode:${errData.code}  message:${errData.message});
        })
      })


      // 示例二：读取data.bin文件中的压缩数据并存入一个缓冲区，调用uncompress接口将缓冲区中的数据解压到目标缓冲区，并将目标缓冲区的内容写入文件data.txt
      Button('uncompress buffer').onClick(() => {
        let path = getContext(this).filesDir;
        let inFile = fs.openSync(path + '/data.bin', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        let outFile = fs.openSync(path + '/data.txt', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        // 读取data.bin文件中的压缩数据，并存入缓冲区inBuf
        let stat = fs.statSync(inFile.path);
        let inBuf = new ArrayBuffer(stat.size);
        let readLen = fs.readSync(inFile.fd, inBuf);
        console.info(compressed data size: ${stat.size}, read len: ${readLen});
        // 创建一个目标缓冲区，此处的dataSize是我们进行数据压缩前保存的数据的原始大小
        let outBuf = new ArrayBuffer(this.dataSize);
        console.info(the dest buf size is ${this.dataSize});
        // 创建一个压缩对象实例
        let zip = zlib.createZipSync();
        // 将inBuf中的数据解压缩outBuf中
        zip.uncompress(outBuf, inBuf, readLen).then((zipOutInfo) => {
          console.info(uncompress success, status ${zipOutInfo.status}, destLen  ${zipOutInfo.destLen});
          // 将outBuf中的数据写入到data.txt文件
          let writeLen = fs.writeSync(outFile.fd, outBuf, { length: zipOutInfo.destLen });
          console.info(write destBuf to data.txt, writeLen ${writeLen});
          // 关闭文件
          fs.closeSync(inFile.fd);
          fs.closeSync(outFile.fd);
        }).catch((errData: BusinessError) => {
          console.error(errData is errCode:${errData.code}  message:${errData.message});
        })
      })
    }
    .height('100%')
    .width('100%')
  }
}

未知大小缓冲区的压缩与解压（zlib格式）：

import { fileIo as fs} from '@kit.CoreFileKit';
import { BusinessError, zlib } from '@kit.BasicServicesKit';


@Entry
@Component
struct Index {
  build() {
    Row() {
      // 示例一：从文件中不断读取数据进行压缩
      Button('deflateFile').onClick(() => {
        let path = getContext(this).filesDir;
        let inFile = fs.openSync(path + '/data.txt', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        let outFile = fs.openSync(path + '/data.bin', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        deflateFile(inFile, outFile).then(() => {
          console.info('deflateFile success');
          fs.closeSync(inFile.fd);
          fs.closeSync(outFile.fd);
        })
      })


      // 示例二：从文件中不断读取压缩数据进行解压
      Button('inflateFile').onClick(() => {
        let path = getContext(this).filesDir;
        let inFile = fs.openSync(path + '/data.bin', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        let outFile = fs.openSync(path + '/data.txt', fs.OpenMode.READ_WRITE | fs.OpenMode.CREATE);
        inflateFile(inFile, outFile).then(() => {
          console.info('deflateFile success');
          fs.closeSync(inFile.fd);
          fs.closeSync(outFile.fd);
        })
      })
    }
    .height('100%')
    .width('100%')
  }
}


// 从一个文件中，不断的读入数据，进行压缩，并写入到另一个文件中
async function deflateFile(src: fs.File, dest: fs.File) {
  let flush = zlib.CompressFlushMode.NO_FLUSH;
  let strm: zlib.ZStream = {};  //初始化一个压缩流
  const BUFLEN = 4096;
  let inBuf = new ArrayBuffer(BUFLEN);  // 初始化一个输入缓冲区
  let outBuf = new ArrayBuffer(BUFLEN); // 初始化一个输出缓冲区
  // 创建一个压缩对象实例
  let zip = zlib.createZipSync();
  // 初始化流的状态
  let initStatus = zip.deflateInit(strm, zlib.CompressLevel.COMPRESS_LEVEL_BEST_SPEED);
  console.info('deflateInit ret: ' + (await initStatus).valueOf());
  do {
    // 从文件中读取数据到缓冲区
    let readLen = fs.readSync(src.fd, inBuf);
    console.info("readSync readLen: " + readLen);
    flush = readLen == 0 ? zlib.CompressFlushMode.FINISH : zlib.CompressFlushMode.NO_FLUSH;
    // 设置输入缓冲区
    strm.availableIn = readLen;
    strm.nextIn = inBuf;
    do {
      // 设置输出缓冲区
      strm.availableOut = BUFLEN;
      strm.nextOut = outBuf;
      try {
        // 压缩输入缓冲区中数据到输出缓冲区
        let deflateStatus = zip.deflate(strm, flush);
        console.info('deflate ret: ' + (await deflateStatus).valueOf());
        // 更新流的状态
        let innerStrm = zip.getZStream();
        strm.availableIn = (await innerStrm).availableIn;
        strm.nextIn = (await innerStrm).nextIn;
        strm.availableOut = (await innerStrm).availableOut;
        strm.nextOut = (await innerStrm).nextOut;
        strm.totalIn = (await innerStrm).totalIn;
        strm.totalOut = (await innerStrm).totalOut;


        if (strm.availableOut != undefined) {
          // 将已完成压缩的数据，写入到输出文件中
          let have = BUFLEN - strm.availableOut;
          let writeLen = fs.writeSync(dest.fd, outBuf, { length: have });
          console.info(writeSync writeLen: ${writeLen});
        }
      } catch (err) {
        console.error('deflate err: ' + JSON.stringify(err));
      }
    } while (strm.availableOut == 0); // 循环压缩输入缓冲区中剩余的数据，直到全部完成压缩
  } while (flush != zlib.CompressFlushMode.FINISH); // 循环从文件中读取数据，直到数据全部读取
  // 释放资源
  zip.deflateEnd(strm);
}


// 从一个文件中，不断的读入已压缩的数据，进行解压，并写入到另一个文件中
async function inflateFile(src: fs.File, dest: fs.File) {
  let status: zlib.ReturnStatus = zlib.ReturnStatus.OK;
  let strm: zlib.ZStream = {};  //初始化一个压缩流
  const BUFLEN = 4096;
  let inBuf = new ArrayBuffer(BUFLEN);  // 初始化一个输入缓冲区
  let outBuf = new ArrayBuffer(BUFLEN); // 初始化一个输出缓冲区
  // 创建一个压缩对象实例
  let zip = zlib.createZipSync();
  // 初始化流的状态
  let initStatus = zip.inflateInit(strm);
  console.info('inflateInit ret: ' + (await initStatus).valueOf());
  do {
    // 从文件中读取已压缩的数据到缓冲区
    let readLen = fs.readSync(src.fd, inBuf);
    console.info("readSync readLen: " + readLen);
    if (readLen == 0) {
      break;
    }
    // 设置输入缓冲区
    strm.availableIn = readLen;
    strm.nextIn = inBuf;
    do {
      // 设置输出缓冲区
      strm.availableOut = BUFLEN;
      strm.nextOut = outBuf;
      try {
        // 解压输入缓冲区中数据到输出缓冲区
        let inflateStatus = zip.inflate(strm, zlib.CompressFlushMode.NO_FLUSH);
        console.info('inflate ret: ' + (await inflateStatus).valueOf());
        // 更新流的状态
        let innerStrm = zip.getZStream();
        strm.availableIn = (await innerStrm).availableIn;
        strm.nextIn = (await innerStrm).nextIn;
        strm.availableOut = (await innerStrm).availableOut;
        strm.nextOut = (await innerStrm).nextOut;
        strm.totalIn = (await innerStrm).totalIn;
        strm.totalOut = (await innerStrm).totalOut;


        if (strm.availableOut != undefined) {
          // 将已完成解压的数据，写入到输出文件中
          let have = BUFLEN - strm.availableOut;
          let writeLen = fs.writeSync(dest.fd, outBuf, { length: have });
          console.info(writeSync writeLen: ${writeLen});
        }
      } catch (err) {
        console.error('inflate err: ' + JSON.stringify(err));
      }
    } while (strm.availableOut == 0)  // 循环解压输入缓冲区中剩余的数据，直到全部完成解压
  } while (status != zlib.ReturnStatus.STREAM_END.valueOf())  // 循环从文件中读取数据，直到数据全部读取
  // 释放资源
  zip.inflateEnd(strm);
}
