【HarmonyOS Next之旅】基于ArkTS开发(一) -＞ Ability开发二 原创 精华

import featureAbility from '@ohos.ability.featureAbility'
 import dataAbility from '@ohos.data.dataAbility'
 import dataRdb from '@ohos.data.rdb'

 const TABLE_NAME = 'book'
 const STORE_CONFIG = { name: 'book.db' }
 const SQL_CREATE_TABLE = 'CREATE TABLE IF NOT EXISTS book(id INTEGER PRIMARY KEY AUTOINCREMENT, name TEXT NOT NULL, introduction TEXT NOT NULL)'
 let rdbStore: dataRdb.RdbStore = undefined

 export default {
 onInitialized(abilityInfo) {
     console.info('DataAbility onInitialized, abilityInfo:' + abilityInfo.bundleName)
     let context = featureAbility.getContext()
     dataRdb.getRdbStore(context, STORE_CONFIG, 1, (err, store) => {
         console.info('DataAbility getRdbStore callback')
         store.executeSql(SQL_CREATE_TABLE, [])
         rdbStore = store
     });
 },
 insert(uri, valueBucket, callback) {
     console.info('DataAbility insert start')
     rdbStore.insert(TABLE_NAME, valueBucket, callback)
 },
 batchInsert(uri, valueBuckets, callback) {
     console.info('DataAbility batch insert start')
     for (let i = 0;i < valueBuckets.length; i++) {
         console.info('DataAbility batch insert i=' + i)
         if (i < valueBuckets.length - 1) {
             rdbStore.insert(TABLE_NAME, valueBuckets[i], (err: any, num: number) => {
                 console.info('DataAbility batch insert ret=' + num)
             })
         } else {
             rdbStore.insert(TABLE_NAME, valueBuckets[i], callback)
         }
     }
 },
 query(uri, columns, predicates, callback) {
     console.info('DataAbility query start')
     let rdbPredicates = dataAbility.createRdbPredicates(TABLE_NAME, predicates)
     rdbStore.query(rdbPredicates, columns, callback)
 },
 update(uri, valueBucket, predicates, callback) {
     console.info('DataAbilityupdate start')
     let rdbPredicates = dataAbility.createRdbPredicates(TABLE_NAME, predicates)
     rdbStore.update(valueBucket, rdbPredicates, callback)
 },
 delete(uri, predicates, callback) {
     console.info('DataAbilitydelete start')
     let rdbPredicates =
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
41.
42.
43.
44.
45.
46.
47.
48.
49.

"abilities":[{
 "srcPath": "DataAbility",
 "name": ".DataAbility",
 "icon": "$media:icon",
 "srcLanguage": "ets",
 "description": "$string:description_dataability",
 "type": "data",
 "visible": true,
 "uri": "dataability://ohos.samples.etsdataability.DataAbility"
1.
2.
3.
4.
5.
6.
7.
8.
9.

// 作为参数传递的Uri,与config中定义的Uri的区别是多了一个"/",是因为作为参数传递的uri中,在第二个与第三个"/"中间,存在一个DeviceID的参数
import featureAbility from '@ohos.ability.featureAbility'
import ohos_data_ability from '@ohos.data.dataAbility'
import ohos_data_rdb from '@ohos.data.rdb'

var urivar = "dataability:///com.ix.DataAbility"
var DAHelper =
1.
2.
3.
4.
5.
6.
7.

var valuesBucket = {"name": "gaolu"}
var da = new ohos_data_ability.DataAbilityPredicates()
var valArray =new Array("value1");
var cars = new Array({"batchInsert1" : "value1",});
1.
2.
3.
4.

// callback方式调用:
DAHelper.insert(
 urivar,
 valuesBucket,
 (error, data) => {
     console.log("DAHelper insert result: "
1.
2.
3.
4.
5.
6.

// promise方式调用:
var datainsert =
1.
2.

// callback方式调用:
DAHelper.delete(
 urivar,
 da,
 (error, data) => {
     console.log("DAHelper delete result: "
1.
2.
3.
4.
5.
6.

// promise方式调用:
var datadelete =
1.
2.

// callback方式调用:
DAHelper.update(
 urivar
 valuesBucket,
 da,
 (error, data) => {
     console.log("DAHelper update result: "
1.
2.
3.
4.
5.
6.
7.

// promise方式调用:
var dataupdate =
1.
2.

// callback方式调用:
DAHelper.query(
 urivar,
 valArray,
 da,
 (error, data) => {
     console.log("DAHelper query result: "
1.
2.
3.
4.
5.
6.
7.

// promise方式调用:
var dataquery =
1.
2.

// callback方式调用:
DAHelper.batchInsert(
 urivar,
 cars,
 (error, data) => {
     console.log("DAHelper batchInsert result: "
1.
2.
3.
4.
5.
6.

// promise方式调用:
var databatchInsert =
1.
2.

// callbacke方式调用:
DAHelper.executeBatch(
 urivar,
 [
     {
         uri: urivar,
         type: featureAbility.DataAbilityOperationType.TYPE_INSERT,
         valuesBucket: {"executeBatch" : "value1",},
         predicates: da,
         expectedCount:0,
         predicatesBackReferences: null,
         interrupted:true,
     }
 ],
 (error, data) => {
     console.log("DAHelper executeBatch result: "
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.

// promise方式调用:
var dataexecuteBatch = await DAHelper.executeBatch(
 urivar,
 [
     {
         uri: urivar,
         type: featureAbility.DataAbilityOperationType.TYPE_INSERT,
         valuesBucket:
         {
             "executeBatch" : "value1",
         },
         predicates: da,
         expectedCount:0,
         predicatesBackReferences: null,
         interrupted:true,
     }
 ]
);
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.

import formBindingData from '@ohos.application.formBindingData'
import formInfo from '@ohos.application.formInfo'
import formProvider from '@ohos.application.formProvider'
1.
2.
3.

export default {
    onCreate(want) {
        console.log('FormAbility onCreate');
        // 由开发人员自行实现，将创建的卡片信息持久化，以便在下次获取/更新该卡片实例时进行使用
        let obj = {
            "title": "titleOnCreate",
            "detail": "detailOnCreate"
        };
        let formData = formBindingData.createFormBindingData(obj);
        return formData;
    },
    onCastToNormal(formId) {
        // 使用方将临时卡片转换为常态卡片触发，提供方需要做相应的处理
        console.log('FormAbility onCastToNormal');
    },
    onUpdate(formId) {
        // 若卡片支持定时更新/定点更新/卡片使用方主动请求更新功能，则提供方需要覆写该方法以支持数据更新
        console.log('FormAbility onUpdate');
        let obj = {
            "title": "titleOnUpdate",
            "detail": "detailOnUpdate"
        };
        let formData = formBindingData.createFormBindingData(obj);
        formProvider.updateForm(formId, formData).catch((error) => {
            console.log('FormAbility updateForm, error:' + JSON.stringify(error));
        });
    },
    onVisibilityChange(newStatus) {
        // 使用方发起可见或者不可见通知触发，提供方需要做相应的处理
        console.log('FormAbility onVisibilityChange');
    },
    onEvent(formId, message) {
        // 若卡片支持触发事件，则需要覆写该方法并实现对事件的触发
        console.log('FormAbility onEvent');
    },
    onDestroy(formId) {
        // 删除卡片实例数据
        console.log('FormAbility onDestroy');
    },
    onAcquireFormState(want) {
        console.log('FormAbility onAcquireFormState');
        return
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
41.
42.

"js": [{
       "name": "widget",
       "pages": ["pages/index/index"],
       "window": {
           "designWidth": 720,
           "autoDesignWidth": true
       },
       "type": "form"
1.
2.
3.
4.
5.
6.
7.
8.

"abilities": [{
       "name": "FormAbility",
       "description": "This is a FormAbility",
       "formsEnabled": true,
       "icon": "$media:icon",
       "label": "$string:form_FormAbility_label",
       "srcPath": "FormAbility",
       "type": "service",
       "srcLanguage": "ets",
       "forms": [{
           "colorMode": "auto",
           "defaultDimension": "2*2",
           "description": "This is a service widget.",
           "formVisibleNotify": true,
           "isDefault": true,
           "jsComponentName": "widget",
           "name": "widget",
           "scheduledUpdateTime": "10:30",
           "supportDimensions": ["2*2"],
           "type": "JS",
           "updateDuration": 1,
           "updateEnabled": true
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.

'FormAbility onCreate');

           let formId = want.parameters["ohos.extra.param.key.form_identity"];
           let formName = want.parameters["ohos.extra.param.key.form_name"];
           let tempFlag = want.parameters["ohos.extra.param.key.form_temporary"];
           // 由开发人员自行实现，将创建的卡片信息持久化，以便在下次获取/更新该卡片实例时进行使用
           storeFormInfo(formId, formName, tempFlag, want);

           let obj = {
               "title": "titleOnCreate",
               "detail": "detailOnCreate"
           };
           let formData = formBindingData.createFormBindingData(obj);
           return
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.

<div class="container">
  <stack>
   <div class="container-img">
       <image src="/common/widget.png" class="bg-img"></image>
   </div>
   <div class="container-inner">
       <text class="title">{{title}}</text>
       <text class="detail_text" onclick="routerEvent">{{detail}}</text>
   </div>
  </stack>
</div>
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.

.container {
 flex-direction: column;
 justify-content: center;
 align-items: center;
}

.bg-img {
 flex-shrink: 0;
 height: 100%;
}

.container-inner {
 flex-direction: column;
 justify-content: flex-end;
 align-items: flex-start;
 height: 100%;
 width: 100%;
 padding: 12px;
}

.title {
 font-size: 19px;
 font-weight: bold;
 color: white;
 text-overflow: ellipsis;
 max-lines: 1;
}

.detail_text {
 font-size: 16px;
 color: white;
 opacity: 0.66;
 text-overflow: ellipsis;
 max-lines: 1;
 margin-top: 6px;
}
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
32.
33.
34.
35.
36.

{
"data": {
  "title": "TitleDefault",
  "detail": "TextDefault"
},
"actions": {
  "routerEvent": {
 "action": "router",
 "abilityName": "com.example.MyApplication.hmservice.FormAbility",
 "params": {
   "message": "add detail"
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.

import wantAgent from '@ohos.wantAgent';
1.

private wantAgentObj = null    //用于保存创建成功的wantAgent对象，后续使用其完成触发的动作。

//wantAgentInfo
var wantAgentInfo = {
    wants: [
        {
            deviceId: "",
            bundleName: "com.example.test",
            abilityName: "com.example.test.MainAbility",
            action: "",
            entities: [],
            uri: "",
            parameters: {}
        }
    ],
    operationType: wantAgent.OperationType.START_ABILITY,
    requestCode: 0,
    wantAgentFlags:[wantAgent.WantAgentFlags.CONSTANT_FLAG]
}
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.

private wantAgentObj = null    //用于保存创建成功的WantAgent对象，后续使用其完成触发的动作。

//wantAgentInfo
var wantAgentInfo = {
    wants: [
        {
            action: "event_name", // 设置事件名
            parameters: {}
        }
    ],
    operationType: wantAgent.OperationType.SEND_COMMON_EVENT,
    requestCode: 0,
    wantAgentFlags:[wantAgent.WantAgentFlags.CONSTANT_FLAG]
}
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.

//创建WantAgent
wantAgent.getWantAgent(wantAgentInfo, (err, wantAgentObj) => {
    if (err.code) {
        console.error("[WantAgent]getWantAgent err=" + JSON.stringify(err))
    } else {
        console.log("[WantAgent]getWantAgent success")
        this.wantAgentObj = wantAgentObj
    }
})
1.
2.
3.
4.
5.
6.
7.
8.
9.

//触发WantAgent
var triggerInfo = {
    code:0
}
wantAgent.trigger(wantAgentObj, triggerInfo, (completeData) => {
    console.log("[WantAgent]getWantAgent success, completeData: ",  + JSON.stringify(completeData))
})
1.
2.
3.
4.
5.
6.
7.
